NEC SL 1000 - SLIU CODEC Filter Data Setup

Program 82 : Basic Hardware Setup for
Extension
82-09 : SLIU CODEC Filter Data Setup
Level:
IN
Description
Use Program 82-09 : SLIU CODEC Filter Data Setup to define the filter setting data (when Program
82-07 is set to 4).
Input Data
Item
No.
Item Input Data Default
01 B1 Filter Setup (1) 0 ~ 255 105
02 B1 Filter Setup (2) 0 ~ 255 122
03 B1 Filter Setup (3) 0 ~ 255 166
04 B1 Filter Setup (4) 0 ~ 255 42
05 B1 Filter Setup (5) 0 ~ 255 227
06 B1 Filter Setup (6) 0 ~ 255 46
07 B1 Filter Setup (7) 0 ~ 255 169
08 B1 Filter Setup (8) 0 ~ 255 242
09 B1 Filter Setup (9) 0 ~ 255 151
10 B1 Filter Setup (10) 0 ~ 255 41
11 B1 Filter Setup (11) 0 ~ 255 122
12 B1 Filter Setup (12) 0 ~ 255 135
13 B1 Filter Setup (13) 0 ~ 255 168
14 B1 Filter Setup (14) 0 ~ 255 112
15 B2 Filter Setup (1) 0 ~ 255 45
16 B2 Filter Setup (2) 0 ~ 255 1
17 AISN and Analog Gains 0 ~ 255 14
18 Z Filter Coefficients (1) 0 ~ 255 178
19 Z Filter Coefficients (2) 0 ~ 255 162
20 Z Filter Coefficients (3) 0 ~ 255 53
21 Z Filter Coefficients (4) 0 ~ 255 83
22 Z Filter Coefficients (5) 0 ~ 255 42
23 Z Filter Coefficients (6) 0 ~ 255 171
24 Z Filter Coefficients (7) 0 ~ 255 194
25 Z Filter Coefficients (8) 0 ~ 255 43
26 Z Filter Coefficients (9) 0 ~ 255 106
27 Z Filter Coefficients (10) 0 ~ 255 163
