Programming Status Change Options
100 AFP-200 PN 15511:H2 10/14/2002
the control panel sends a trouble banner (“TEST Txx”) to the History buffer and
optional printer.
• Turns off the System Alarm relay.
Doing a Walk Test
This section contains instructions for performing a Standard and Silent Walk Test.
Follow these procedures for doing both types of Walk Test. The difference between a
Standard and Silent Walk Test is the programming of the outputs as shown in“How to
Edit or Delete a Point (2=point)” on page 78.
To do a Standard Walk Test, follow these steps:
1. From the Status Change screen (Figure 84 on page 93), press the 6 key to display
the Walk Test Entry screen as shown in Figure 94:
Figure 94 Walk Test Entry Screen
To stop Walk Test at any time,
press the BACKSPACE key
and the control panel returns
to the Status Change screen.
A 1-hour timer automatically
returns the control panel to
normal operation after 1 hour
of inactivity.
2. From the Walk Test Entry screen, press the ENTER key. The control panel goes into
Walk Test and the Walk Test screen appears as shown in Figure 95:
Figure 95 The LCD Display in Walk Test
3. Test your output devices.
4. When finished with the Walk Test, press the
BACKSPACE key to return the control
panel to normal operation as shown in the sample screen in Figure 96.
Figure 96 Sample LCD Display in Normal Operation
5. View the History buffer and printer output (if installed) to check the results of the
Walk Test.
WARNING: When finished doing a Walk Test:
• Exit Walk Test immediately and return the system to normal operation.
• Notify the building owner/operator, fire department, and other persons that
testing is complete and the system is operating normally.
Status Change
Password
WALK@TEST@PRESS
ENTER@TO@START
BACKSPACE@TO@STOP
WALK@TEST@PRESS
BACKSPACE@TO@STOP
Second line goes
blank in Walk Test
ALL@SYSTEMS@NORMAL
11:13A@@SUN@12/25/97
!
