Read Status Operation
AFP-200 PN 15511:H2 10/14/2002 121
Software Zones 01-89
To read the status of a zone directly, press *, press * again, then enter the two-digit zone
number and press the
ENTER key. Figure 116 contains a typical display that shows the
status of zone 20:
Figure 116 Typical Zone Read Status Screen
Software Zone 90
Figure 117 contains a typical display that shows the status of software zone 90
(Presignal delay control).
Figure 117 Typical Presignal Delay Screen
Software Zones 91, 92, 93, and 94
Figure 118 shows a typical display for the status of a releasing control zone (software
zones 91, 92, 93, or 94):
Figure 118 Typical Display for a Releasing Control Zone
Zone Number
OFF@SOFTWARE@ZONE
FLR@5@MAIN@BUILDING
Z20
OFF is the zone status (status can
be ON or OFF).
FLR 5 MAIN BUILDING
is the custom label
programmed for this
zone.
Z20 is the zone
number.
OFF@SOFTWARE@ZONE
PRESIGNAL@DELAY
DELAY=180
PAS=YES @@@@@@@Z90
DELAY=180 indicates the
programmed Presignal
delay in seconds.
PAS=YES (could be NO) indicates that Positive Alarm
Sequence operation is selected in the program.
OFF is the zone status (status can
be ON or OFF).
Z90 is the zone
number.
Zone Number
OFF@SOFTWARE@ZONE
RELEASE@CONTROL
DELAY=30@ABORT=ULI
CROSS=Y@SOAK=10@Z91
DELAY=30 indicates
programmed delay
time in seconds.
ABORT=ULI indicates the
abort function, if an abort
switch is mapped to this
zone (ULI, IRI, NYC, or
AHJ).
CROSS=Y indicates that
cross zoning is used (must
have two or more detectors
programmed to this zone in
alarm to activate the zone).
SOAK indicates the soak timer (automatic shut
off) value in minutes (00 = no soak timer).
OFF is the zone status
(status can be ON or OFF).
Z91 is the zone number.
