Programming How to Enter Program Change
88 AFP-200 PN 15511:H2 10/14/2002
From the Special Zone Change screen (Figure 74), key in “90” to display the Presignal
screen. Figure 75 shows a typical Presignal screen.
Figure 75 Presignal Screen
From the Presignal screen, you can change the delay time or the PAS selection. Refer to
Appendix H for a detailed explanation of Presignal and PAS.
Releasing Control Zones (Zones 91-94)
From the Special Zone Change screen (Figure 74), you can key in 91, 92, 93, or 94 to
display the Release Control screen (Figure 76). You can change delay times
(0-60 seconds), abort type (ULI, IRI, NYC or AHJ), cross zoning (N,Y, H, or Z) or soak
time (00, 10-15 minutes). Figure 76 shows a typical display:
Figure 76 Release Control Screen
For descriptions and options for releasing zones, refer to Appendix D “Releasing
Applications”
.
Time Control Change (Zones 95, 96)
Time Control lets you change the start time, stop time, or days of the week. From the
Special Zone Change screen (Figure 74), you can key in 95 or 96 to display the Time
Control Change screen. Figure 77 shows a typical screen for changing the time using
software zone 95:
Figure 77 Time Control Change Screen
For descriptions and options for Time Control zones, refer to Appendix H “Special
Zones”.
Holiday Change (Zone 97)
Software zone 97 (Holiday Change) lets you select up to nine holiday dates. Any device
programmed to Software Zone 97 will be active on the holiday dates listed. From the
Special Zone Change screen (Figure 74), key in 97 to display the Holiday Change
screen. Figure 78 shows a typical Holiday Change screen:
Figure 78 Holiday Change Screen
PRG@SOFTWARE@ZONE
PRESIGNAL@DELAY
DELAY=180
PAS=YES Z90
PRG@SOFTWARE@ZONE
RELEASE@@@CONTROL
DELAY=00@@ABORT=ULI
CROSS=Y@@@SOAK=00 Z91
PRG@SOFTWARE@ZONE
TIME@CONTROL
ON=08:00@@@OFF=17:00
DAYS=SMTWTFSH@@@@@@@Z95
PRG@HOLIDAY@ZONE 97
01/01@@04/10@@05/26
07/04@@09/07@@11/26
11/27@@12/24@@12/25
