Maintain the scanner
Clean the scanner
Introduction
#
Description / FunctionComponent
Exits originals for reception into the front
original tray.
originals exit1
Use this ruler to measure the original.original size ruler2
A set of rollers used to transport the origi-
nal.
original feed rollers3
Top cover of the scanner.scanner top cover4
Lever to open the top cover of the scanner.scanner open levers5
A set of rollers to guide the original.original support rollers6
A set of rollers in the top cover to guide the
original.
scanner top cover rollers7
Sensors to detect the original.original sensors8
Cover of the image sensors.transparent contact plates9
