Oce PlotWave 350 - The Components of the Scanner (Optional); Chapter 2; Get to Know the Printing

The components of the scanner (optional)
Attention:
The 'Océ Scanner Express' is only available in the Océ PlotWave 350 and Océ PlotWave
350 multifunction Express.
Note:
The scanner calibration sheet for the 'Océ Scanner Express' is located in the media
drawer at the rear of roll 2.
Illustration
5
1
4
3
2
Component - function table
#
Description / FunctionComponent
scanner top cover1
Use the original feeding table to feed the
original into the scanner (face up).
original feeding table2
Use the scanner open levers to open the
scanner top cover.
scanner open levers3
Chapter 2 - Get to know the printing system40
The components of the scanner (optional)
