The components of the printer (back)
Illustration
Component - function table
#
Description / FunctionComponentNr
Switch to cycle on or off the mains power.
You can find the serial number of the
printer on the sticker above the power
switch.
power switch1
Open the upper back cover with the media
jam clearance handle to access the fuser
section in case of a media jam in the fuser
section.
upper back cover2
Use this handle to access the paper in case
of a paper jam.
media jam clearance handle3
Chapter 2 - Get to know the printing system 33
The components of the printer (back)
To Next Page
