206
Comparison Section 5-5
2. Input the set value set command code C710 for the L set value. To input
the letter C with the Programming Console, press the Shift and 2 Keys.
The input word will be set to the response C710.
3. Set 0000 to the output word.
4. When the Unit correctly receives the command, the input word will be set
to 0000.
5. Input the set value set command code C720 for the H set value. The input
word will be set to the response C720.
6. Set 2000 to the output word.
7. When the Unit correctly receives the command, the input word will be set
to 2000.
8. Input the hysteresis set command code CA00.
The input word will be set to the response CA00.
9. Set 0010 to the output word.
10. When the Unit correctly receives the command, the input word will be set
to 0010.
11. After setting all the set values, set the output word to 0000 again. The
scaled conversion data 1254 will be set to the input word.
