JExamples of use
F Set the unit No. to “00”
• In the following examples, data is shown in individual blocks to make the exam-
ples easier to understand. However, when actually creating programs, do not leave
spaces between frame items. Also, response are displayed without spaces between
frame items.
F Set the set point to “300.0”
• Input data
@ 00 2 01 3000
300.0
Set point
Write parameter
• Response
@ 00 2 01 00 3000 (FCS) *
Normal end
F Start running
• Input data
@ 00 3 00 0000
Run
Run/Stop
Special command
• Response
@ 00 3 00 00 0000 (FCS) *
Normal end
F Monito r process value
• Input data
@ 00 1 00 0000
Dummy data
Monitor process value
Read parameter
• Response
@ 00 1 00 00 2000 (FCS) *
Process value = 2000
Normal end
