8.1 Dimension Drawings
Table 8-1. eCobra 600 Robot Top and Side Dimension Description
Item Description
1 Required Clearance to Open eAIB Chassis
2 31 mm Required Cable Clearance
417
183
200
918
894
398
342
184
0
46
37
800
425
0
234
1
2
Figure 8-2. eCobra 800 Robot Top and Side Dimensions (Units in mm)
