Chapter 5: System Operation
XIO Output Specifications
Table 5-9. XIO Output Circuit Specifications
Parameter Value
Power supply voltage range See Specifications for 24 VDC
Power on page 50.
Operational current range, per chan-
nel
I
out
≤ 700 mA
Total Current Limitation, all chan-
nels on.
I
total
≤ 1.0 A @ 50° C ambient
I
total
≤ 1.5 A @ 25° C ambient
On state resistance (I
out
= 0.5 A)
R
on
≤ 0.32 Ω @ 85° C
Output leakage current I
out
≤ 25 µA
Turn-on response time 125 µsec max., 80 µsec typical
(hardware only)
Turn-off response time 60 µsec max., 28 µsec typical
(hardware only)
Output voltage at inductive load
turnoff (I
out
= 0.5A, Load = 1 mH)
(+V - 65) ≤V
demag
≤ (+V - 45)
DC short circuit current limit 0.7A ≤ I
LIM
≤ 2.5 A
Peak short circuit current I
ovpk
≤ 4 A
