Section 2 NS Series Functions 2-8 Common Functional Object Functions
2-80
NS Series Programming Manual
Display item Display format
hh: hour, mm: minutes, ss: seconds, xxxx: , XXXX: AM/PM Time
Display formats
xxxx hh[Jh]mm[Jm]ss[Js]
xxxx hh[Jh]mm[Jm]
hh[Jh]mm[Jm]ss[Js]
hh[Jh]mm[Jm]
xxxx hh:mm:ss
xxx hh:mm
hh:mm:ss XXXX
hh:mm XXXX
hh:mm:ss
hh:mm
nn ms (See note.)
n s (See note.)
Display examples
01 51 25
01 51
13
51 25
13
51
10:15:20
10:15
10:15:20 AM
10:15 AM
10:15:20
10:15
1000 ms
1 s
Note: Only data log objects can be used.
R
R
R
e
e
e
f
f
f
e
e
e
r
r
r
e
e
e
n
n
n
c
c
c
e
e
e
♦
Depending on the settings at the CX-Designer, the Japanese characters shown below will be
displayed at the PT.
Display at CX-Designer Display at PT
[JY]
[JM]
[JD]
[Jh]
[Jm]
[Js]
2-8-6 Text Attributes
The text attributes such as font, size, and color can be set for functional objects that display characters.
The text attributes are set on the Text Tab Page.
1
2
3

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
