Section 3 Using PTs 3-10 Prohibiting and Allowing PT Operation
3-30
NS Series Programming Manual
Procedure for Prohibiting and Allowing Input to All Screen Functional Objects
by Manipulating Specified Communications Addresses
1. In the CX-Designer, select PT – System Settings, select the Touch Switch Lock Control Flag in
the PT Tab Page in the System Settings Dialog Box, and then set the desired communications ad-
dress.
2. Specify Prohibit Touch when ON or Prohibit Touch when OFF as the prohibit condition.
3. The following table shows the Touch Switch Lock Control Flag during operation.
Prohibit/allow input Condition Communications address
Prohibit touch when ON OFF to ON (0 to 1) Prohibit input
Prohibit touch when OFF ON to OFF (1 to 0)
Prohibit touch when ON ON to OFF (1 to 0) Allow input
Prohibit touch when OFF OFF to ON (0 to 1)
N
N
N
o
o
o
t
t
t
e
e
e
♦
Unlike with $SB19 in the system memory, a dialog box for the password to cancel the input prohibit
will not be displayed even if the screen is touched with input prohibited.
♦
The Touch Switch Lock Control Flag has priority if both $SB19 in the system memory and the Touch
Switch Lock Control Flag are used as input prohibit conditions.
♦
Entering the System Menu by pressing two corners of the screen (or by pressing any corner twice for
the NS15) is prohibited when input is prohibited using the Touch Switch Lock Control Flag.
3-10-3 Prohibiting and Allowing Input for Individual Functional Objects
Input to functional objects is controlled by control flags for functional objects on NS-series PTs that
accept input.
Method
1. When creating a screen using CX-Designer, select Control flag - Input - Indirect in the property
settings for each functional object and set the control flag address.
2. Input can be prohibited and allowed by changing the status of the specified control flag address.
Prohibiting input:
Change set address status from ON to OFF (1 → 0).
Allowing input:
Change set address status from OFF to ON (0 → 1).
N
N
N
o
o
o
t
t
t
e
e
e
♦
If disable is set using the control flag, no input from the PT to that functional object is possible dur-
ing operation.
♦
Control flags also have a function for displaying or not displaying functional objects.
To Next Page
