Omron NS Programming Manual

Section 3 Using PTs 3-8 Using Operation Log Functions
3-27
NS Series Programming Manual
3-8-1 Settings for Operation Logs
To record operation histories for functional objects, Record to Operation Log must be selected before-
hand on the Write Tab Page (extension tab page) for each functional object when screens are created
using CX-Designer.
The enables records to be kept for the functional objects.
3-8-2 Checking Operation Logs
1. Display the Operation Log Screen from the Special Screen Tab Page under System Menu. The re-
corded operation log data will be displayed.
2. Operation logs can be displayed in order of occurrence and order of frequency.
3. Execute initialization of operation log data from the Initialize Tab Page under System Menu. Execute
a Multifunction Object for which initializing the Operation Log is set.

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
