Omron NS Programming Manual

Appendices Appendix-5 Controller Link Network Status Read List
A-29
NS Series Programming Manual
Appendix-5 Controller Link Network Status Read List
First read address (n) Bits Status Details
0 to 7 Not used.
8 1: Node address setting range
error
9 1: Duplicated node address
10 1: Inconsistent network parameters
11 1: Hardware error
12 1: Communications controller send
section error
13 Not used.
14 Not used.
n
15
Error information
1: Error log exists
0 to 7 1: Startup node address n+1
8 to 15
Startup/polling node address
1: Polling node address
0 Node 1
1 Node 2
2 Node 3
3 Node 4
4 Node 5
5 Node 6
6 Node 7
7 Node 8
8 Node 9
9 Node 10
10 Node 11
11 Node 12
12 Node 13
13 Node 14
14 Node 15
n+2
15 Node 16
0 Node 17
1 Node 18
2 Node 19
3 Node 20
4 Node 21
5 Node 22
6 Node 23
7 Node 24
8 Node 25
9 Node 26
10 Node 27
11 Node 28
n+3
12
Network participation status
Node 29
13 Node 30
14 Node 31
n+3
15 Node 32
n+4 (Reserved.)
n+5
Network participation status
(Reserved.)
0 to 14 Not used. n+6
15
Local Data Link Participation
Status
0: Local node not participating in
data links or data links not started
1: Local node participating in data
links
