Appendices Appendix-6 Additional NS Series Functions
A-32
NS Series Programming Manual
Appendix-6 Additional NS Series Functions
The following tables show the main functions that have been added or improved with the NS Series
upgrade.
Ver. 3.0
Supplement/
Enhancement
Function
Screen data transfer
through PLCs
Enables transferring screen data to NS Hardware through a PLC and
transferring ladder program to the PLC through the NS Hardware.
Switch Box Function Displays I/O status of addresses on the NS Hardware. Addresses and their
comments can be reused from a ladder program using the Switch Box Utility.
Multiple language support Multiple languages (Simplified Chinese, Korean, Traditional Chinese, etc.) can
be displayed on user screens.
Video capture using a PLC
trigger
Enables performing video captures using system memory ($SW24) as a trigger.
Enhanced parts List Vastly increased library objects for use as buttons and lamps.
Reading CLK status Displays status of CLK Board attached with NS Hardware on the screen.
Macro to set time Automatically sets the time, which as set manually before.
Screen data can be
transferred using Ethernet
directly the first time
Screen data can be transferred using Ethernet directly the first time.
Ver. 4.0
Supplement/
Enhancement
Function
Equipped with USB port as
a standard feature.
Equipped with a USB port as a standard feature enabling display contents to be
printed using USB-compatible general-purpose color printers (e.g., Canon or
Epson printers).
Display possible in up to
32,000 colors.
BMP and JPEG images can now be displayed using up to 32,000 colors.
Screen data capacity
greatly increased.
The data capacity has increased from 4 Mbytes to 20Mbytes.
High-speed drawing The drawing speed is twice that of existing OMRON products.
Ver. 5.0
Supplement/
Enhancement
Function
NS5-series models added. Added NS5-SQ0 (B) -V1 with compact 5.7-inch STN color display.
Object forms can be
selected by user.
The forms of ON/OFF Button, Word Button, Bit Lamp, and Word Lamp objects
can now be specified as BMP or JPEG image files.
Windows fonts can be
used in Button and Lamp
objects.
The labels used in ON/OFF Button, Word Button, Bit Lamp, Word Lamp, and
Command Button objects can now be specified using Windows fonts.
Continuous input can be
received from Bar Code
Reader.
Input order of numeric values and character strings can now be controlled,
allowing continuous input from a bar code reader.
Ver. 1.X projects can be
created and edited.
CX-Designer Ver. 5.0 can be used to create and edit projects for NS System Ver.
1.X.
To Next Page
