1-4-2 Connecting to the Host
The NS-series PTs provide the following two serial communications ports.
Serial port A:
9-pin D-sub connector
RS-232C host (CX-Designer or bar code reader can be connected. See note.)
Serial port B:
9-pin D-sub connector
RS-232C host (CX-Designer or bar code reader can be connected. See note.)
Note: Only one of these can be connected to each port.
Ethernet communications with the host and CX-Designer are possible for the NS15-TX01S-V2,
NS12-TS01(B)-V1/-V2, NS10-TV01(B)-V1/-V2, NS8-TV@1(B)-V1/-V2, NS5-SQ01(B)-V1,
NS5-SQ@1(B)-V2, NS5-TQ@1(B)-V2, and NS5-MQ@1(B)-V2.
Ethernet interface:
8-pin modular connector
10/100Base-T
With the NS15, NS12, and NS10, a Controller Link Interface Unit (NS-CLK21) can be installed to en-
able communications with a Controller Link Network.
Controller Link interface:
Special Connector
Specified shielded twisted-pair cable

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
