Section 3 Using PTs 3-11 Using Memory Cards
3-32
NS Series Programming Manual
Trd@@.csv
001 to 999 (001 to 099 if the output file names are 6 characters or longer)
The ID number for files saved for each group. Beginning with 001, the number is
automatically incremented by 1 each time the output operation is executed. After 999,
the number reverts to 001.
0 to 99
Indicates one less than the group number (1 to 100).
The file name set in the Data Log Properties Dialog Box will be displayed.
The default is Trd.
2. Files can also be saved by storing “0” in $SW37 and turning ON system memory bit $SB36.
The file name will be Trend@.csv, and the logs are saved for all registered groups.
Trend@.csv
001 to 999
Beginning with 001, the number is automatically incremented by 1 each time the save
operation is executed. After 999, the number reverts to 001.
3. The data log can be saved from the Initialize Tab Page on the System Menu. File names are the
same as when using the system memory bit ($SB36).
3-11-4 Saving Operation Logs to Memory Cards
Operation log data can be saved to an CSV file by using any of the following methods.
• Turn ON system memory bit $SB38 from the host.
• Execute a Multifunction Object for which saving the operation log is set.
• Save the operation log from the Data Initialization Tab Page of the System Menu.
• Click the Save Log Button in the Operation Log (Sort by Occurrence) Screen or Operation Log (Sort
by Frequency) Screen.
The name of the CSV file is Operat_yymmdd_hhmmss.CSV
Operat_yymmdd_hhmmss.CSV
Fixed character string
Date when the file is saved
(year, month, and day)
Time when the file is saved
(hour, minutes, and seconds)
3-11-5 Saving Error Logs to Memory Cards
Error log files can be saved by turning ON system memory bit $SB43 or by saving the data from the
Initialize Tab Page on the System Menu. The file name will be MacroErr.csv.
Refer to 2-4 System Memory for details on system memory.
3-11-6 Saving Data Blocks to Memory Cards
A file can be saved in CSV format by pressing icons on the data block object.
When pressing the icon to save the file, the folder DBLK will be automatically created in the Memory
Card, and the file will be saved in the folder.
3-11-7 Saving Captured Images to Memory Cards
Using the Video Control – Video Capture function, a captured image can be saved in bitmap (BMP)
format. The file name can be specified in the property setting dialog box for the command button. When
