Section 2 NS Series Functions 2-9 Buttons
2-120
NS Series Programming Manual
Write: Sets the contents of the write confirmation message when the ON/OFF Button is pressed.
(See note.)
Password: Sets the password to be entered when the ON/OFF Button is pressed. (See note.)
Group: Sets group numbers to exclusive buttons. (See note.)
Control Flag: Sets enable/disable input and display/no display for objects. (See note.)
Macro: Sets macros to be executed. (See note.)
Size/Position: Sets the object size and position. (See note.)
Other: Sets the input sound for individual touch switches to OFF. (See note.)
Note: These tabs are displayed when Display Extension Tabs Option is selected.
General Tab Page
Sets the button action type and address.
1
4
2
3
To Next Page
