Section 2 NS Series Functions 2-12 Display and Input Objects
2-246
NS Series Programming Manual
N
N
N
o
o
o
t
t
t
e
e
e
♦
If indirect reference is specified under Watch Maximum/Minimum Limits settings, use the same type
for the values as set on the General Tab Page for the storage type.
For example, if REAL (real number) is specified on the General Tab Page, set the maximum and
minimum limits as real numbers to the address for indirect reference.
♦
Set the maximum and minimum limits before input if they are to be indirectly specified.
If the maximum and minimum limits are set using the Before inputting numeral macro for the numeral
display and input object, those values will not be reflected in the maximum and minimum limit display
on the keypad.
Flicker Tab Page
Make flicker settings to make the object flicker (flash). Refer to Flicker under 2-8 Common Functional
Object Functions for details.
Write Settings Tab Page
Use the write settings to display a confirmation dialog box before writing values to a write address. The
confirmation message can be changed. Refer to Write Settings under 2-8 Common Functional Object
Functions for details.
N
N
N
o
o
o
t
t
t
e
e
e
♦
The write confirmation dialog box will not be displayed if no value is entered and the ENTER Button
on the tenkey pad is pressed or ENT or RET is sent using a Command Button (Key Button). The
contents of the address set under Turn ON the specified address when the value is confirmed will not
turn ON either.
Password Tab Page
A password can be set for when the object area is pressed. Five passwords of up to 16 characters
each can be set. One password can be requested for each object. Refer to Passwords under 2-8
Common Functional Object Functions for details.
Control Flag Tab Page
Control flags control the input and display of functional objects. Use control flags to enable display or
input when the contents of an address turn ON or OFF. Refer to Control Flags under 2-8 Common
Functional Object Functions for details.
To display but not input numerals, change the control flag settings to Disable input.
Macro Tab Page
Macros can be specified for display and input objects.
Macros executed by the following triggers can be registered.
Trigger Details
Before Inputting Numeral Executes macro before numeral input starts.
Before Writing Numeral Executes macro immediately before the numeric value is written.
When Changing Numeral Executes macro when the numerals change.
A value comparison macro can be registered only for a Numeral Display & Input object.
Trigger Details
Value = Set value Executes macro when the value stored at the communications address equals the set
value.
Value > Set value Executes macro when the value stored at the communications address is greater than
the set value.
Value < Set value Executes macro when the value stored at the communications address is less than the
set value.
To Next Page
