Section 2 NS Series Functions 2-12 Display and Input Objects
2-256
NS Series Programming Manual
Write Tab Page
Use the write settings to display a confirmation dialog box before writing values to a write address. The
confirmation message can be changed. Refer to Write Settings under 2-8 Common Functional Object
Functions for details.
Password Tab Page
A password can be set for when the object area is pressed. Five passwords of up to 16 characters
each can be set. One password can be requested for each object. Refer to Passwords under 2-8
Common Functional Object Functions for details.
Control Flag Tab Page
Control flags control the input and display of functional objects. Use control flags to enable display or
input when the contents of an address turn ON or OFF. Refer to Control Flags under 2-8 Common
Functional Object Functions for details.
To display but not input numerals, change the control flag settings to Disable input.
Macro Tab Page
Macros can be specified for string display and input objects. Macros executed by the following triggers
can be registered.
Trigger Details
Before writing numeral Executes macro immediately before the numeric value is written.
When Changing
numeral
Executes macro when the numerals change.
Refer to NS-series Macro Reference in the CX-Designer for information on setting methods.
Size/Position Tab Page
Displays and sets the functional object size and position. Refer to Size/Position under 2-8 Common
Functional Object Functions for details.
