Section 2 NS Series Functions 2-14 Alarms and Events
2-325
NS Series Programming Manual
Select ON.
Click the Write Button.
5. Click the EXIT Button to close the System Menu.
Operation on the NS-series PT
1. Select an alarm or event from the alarm/event and history when an alarm or event is generated.
2. The following confirmation message will be displayed. The message depends on the settings in the
alarm/event summary and history.
• The following dialog box will be displayed if switching to a specified page was set when registering
the alarm/event.
• The following dialog box will be displayed if switching to a specified page was not set when register-
ing the alarm/event.
Click either the Start up Ladder Monitor Button or OK Button in the relevant message dialog box.
3. The Ladder Monitor will start and automatically search for the program section used to output the
communications address of the selected alarm or event. The Ladder Monitor starts searching from
the first line and displays the first program section found.

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
