Section 5 Troubleshooting and Maintenance 5-2 Error Messages
5-23
NS Series Programming Manual
Errors Suggested cause as displayed Possible countermeasure
No destination address set on
routing table (SRES:01).
Set the destination address on the routing table.
Destination unclear because
there is no routing table
(SRES:02).
Set routing tables to the source, destination, and relay
nodes.
Routing table error (SRES:03). Make the correct routing table settings.
Routing
table error
(MRES:05)
Command used more than 3
levels (SRES:04).
Edit the network or change the routing tables so that
the command uses 3 or fewer levels.
Command too long (SRES:01). Check the command format and set the correct
command data.
Command too short (SRES:02). Check the command format and set the correct
command data.
The specified number of ele-
ments and the number of data to
write do not match (SRES:03).
Check and match the number of nodes and the
number of data writes.
Different format (SRES:04). Check the command format and set the correct
command data.
Command
format
error
(MRES:10)
Local node relay table or relay
node local network table settings
incorrect (SRES:05).
Make the correct routing table settings.
No corresponding variable code
or EM (SRES:01).
Check command variables and parameter codes and
set the corresponding code.
Different access size specification
or odd start address specified
(SRES:02).
Check the variable and parameter access sizes and
set the correct access size.
Parameter
error
(MRES:11)
Start address in processing range
for command is in ac-
cess-prohibited area (SRES:03).
Check the allowable processing range and set the
processing range within the allowable range.
End position in processing range
for command is outside allowable
processing range (SRES:04).
Check the allowable processing range and set the
processing range within the allowable range.
Total number of words exceeds
limit (SRES:04).
Make the correct data link table settings.
Non-existent program number set
(SRES:05).
Check the valid program numbers and make the
correct size relationship settings.
Incorrect size relationship for
command elements (SRES:09).
Check the command data and set the correct size
relationships.
Node not set in common link
parameters is set in refresh
parameters (SRES:09).
Make the correct data link table settings.
Tried to execute derivative
monitor during data trace or tried
to execute data trace during
derivative monitoring. (SRES:0A)
Abort the current processing or wait until it has been
completed and then execute the command.
Duplicate node address.
(SRES:0A)
Make the correct data link table settings.
Response exceeds maximum
response length (SRES:0B).
Check the command format and set the correct
number of elements.
Error in set parameters
(SRES:0C).
Check the command data and set the correct
parameters.
Error in file (SRES:0C). Check file contents.
