Appendices Appendix-6 Additional NS Series Functions
A-38
NS Series Programming Manual
Supplement/
Enhancement
Function
Ladder Monitor
• The CJ2 CPU Units are now supported.
• A host can be connected to the PT for monitoring using EtherNet/IP.
Passwords can be set for changing present values and other operations.
Ver. 8.2
Supplement/
Enhancement
Function
Device data transfer Conditions can be set to transfer data from a source to a destination.
SPMA communications Applications running on a computer can access other devices through USB.
Batch format settings The following can be set to the same values for all labels:
• Address information
• List data
• Date display objects
Batch label settings A specified character string can be set for all of the labels for the following ob-
jects:
• Bit Lamp objects
• Bit Button objects
• Multi Function objects
String Display and Input
objects
An input method setting was added to move the cursor to in front of the charac-
ter string when the focus is set.
Analogue Meter improve-
ments
• The shape of the needle can be set to a straight line, arrow, or triangle arrow.
• The line width can be changed to up to 3 dots.
Password input keyboard The user can specify the keyboard used to input a password.
Time setting to move to
System Menu
The time before moving to the System Menu when two of the four corners of the
screen are pressed can be set.
Macro additions Trigonometric and floating-point functions were added.
Screen switch settings The default setting for the display sequence for screens now gives priority to
displaying fixed objects and frames first.
Improvements in creation
methods for fixed objects
The method to create sectors and arcs has been improved.
Data graphs for 128 points The total number of addresses for constant logging was increased to 128 points
max.
Data blocks with 512 KB The size of one data block was increased to 512 KB.
To Next Page
