5-25
V/f Patterns: 0.4 to 1.5 kW
General-purpose Characteristics (Settings 0 to 3)
Setting: 0
Setting: 1 Setting: 2
Setting: 3
15
9
15
9
15
9
15
9
Variable Torque Characteristics (Settings 4 to 7)
Setting: 4
Setting: 5 Setting: 6
Setting: 7
8
9
8
9
30 30
High Starting Torque Characteristics (Settings 8 to b)
Setting: 8
Setting: 9 Setting: A
Setting: b
19
11
24
13
19
11
24
15
High-speed Operation (Settings C to E)
Setting: C
Setting: d
Setting: E
15
9
15
9
15
9
Note The voltages above are for 200-V class Inverters. Double the voltages for 400-V class Inverters.
Basic Operation Chapter 5
