Omron SYSDRIVE 3G3FV User Manual

4-8
4-2-5 Auto-tuning
 Auto-tuning Operation
• Execute auto-tuning and the motor parameters are set automatically.
Key sequence Display Explanation
** Main Menu **
Programming
Displays program mode
** Main Menu **
Auto-Tuning
Displays auto-tuning mode.
Rated Voltage
200.0 VAC
Displays the rated voltage. (see note)
Rated Current
1.90A
Displays the rated current. (see note)
Rated Frequency
60.0 HZ
Displays the rated frequency. (see note)
Rated Speed
1750 RPM
Displays the rated speed. (see note)
Number of Poles
4
Displays the number of poles. (see note)
Select Motor 1/2
1
Displays the motor selection.
(Selections other than “1” can’t be made.)
Tuning Ready ?
Press RUN key
Displays a confirmation prompt for the start of the
auto-tuning function. (The lower line will flash.)
Tune Proceeding
HZ A
Starts the auto-tuning function.
(The upper line will flash.)
Tune Successful
Indicates the completion of auto-tuning.
** Main Menu **
Operation
Returns to the operation mode display.
Note When the values displayed and the motor parameters dif fer , set each value separately . The set -
ting method is as follows. (An operation example for changing the motor parameters current to
1.60 A.
Displays the rated current.
When changing the set values, press the Enter Key and the digit to
change will flash.
Press the Reset/Digit Selection Key three times to make the digit
for changes flash.
Press the Decrement Key and set to 001.60 A.
Press the Enter Key to overwrite the set values. “Entry Accepted”
will be displayed for approximately 0.5 seconds.
Returns to the rated current display.
Rated Current
1.90A
Rated Current
001.90A
Rated Current
001.90A
Rated Current
001.60A
Entry Accepted
Rated Current
1.60A
• When auto-tuning has been executed correctly , the parameters (E1-01 to E2-08) will be automatically
overwritten.
Trial Operation Chapter 4
