Omron SYSDRIVE 3G3FV

6-40
6-5 Common Functions
This section summarizes the functions that can be used in common among the various
modes, and provides detailed explanations of their operations.
6-5-1 Summary of Common Control Functions
An “OK” in the control mode column indicates that the parameter can be changed in that control mode.
The functions that can be used in common are marked with a “ S ” and described in more detail later in
this section.
Group Function Comments
Control mode
G oup
uco
Co e s
V/f V/f
w/PG
Open-loop
Vector
Flux
Vector
Application
b1 Sequence S Settings such as the reference input method OK OK OK OK
ca o
b2 DC Braking S DC braking function settings OK OK OK OK
b3 Speed Search S Speed search function settings OK OK OK OK
b4 Delay Timers S T imer function settings OK OK OK OK
b5 PID Control S PID control settings OK OK OK OK
b6 Reference Hold S Accel/deceleration time dwell function settings OK OK OK OK
b7 Droop Control Droop control settings --- --- --- OK
b8 Energy Saving Multi-function input: Sets energy-saving control by ener -
gy saving reference.
OK OK --- ---
b9 Zero Servo Zero servo settings --- --- --- OK
Tuning
C1 Accel/Decel Acceleration/deceleration time settings OK OK OK OK
ug
C2 S-Curve Acc/Dec S S-curve characteristics for accel/decel times OK OK OK OK
C3 Motor-Slip Comp S Slip compensation function settings OK OK OK OK
C4 T orque Comp S T orque compensation function settings OK OK OK ---
C5 ASR Tuning Speed control tuning --- OK --- OK
C6 Carrier Freq S Carrier frequency settings OK OK OK OK
C7 Hunting Prev Hunting prevention settings OK OK --- ---
C8 Factory Tuning Adjustment for open-loop vector control --- --- OK ---
Reference
d1 Preset Reference Frequency reference settings (when using Operator) OK OK OK OK
eee ce
d2 Reference Limits S Frequency upper and lower limit settings OK OK OK OK
d3 Jump Frequencies S Prohibited frequency settings OK OK OK OK
d4 Sequence S Up/Down, Accel/Decel stop hold frequency setting OK OK OK OK
d5 T orque Control T orque control settings and tuning --- --- --- OK
Motor
E1 V/f Pattern
S Motor settings
OK OK OK OK
oo
E2 Motor Setup
S o o se gs
OK OK OK OK
E3 Control Method 2 S Control mode settings for second motor OK OK OK OK
E4 V/f Pattern 2
S Parameter settings for second motor
OK OK OK OK
E5 Motor Setup 2
S a a e e se gs o seco d o o
OK OK OK OK
Options
F1 PG Option Setup Parameter settings for a PG Speed Control Card --- OK --- OK
Oos
F2 AI-14 Setup S Parameter settings for an Analog Command Card OK OK OK OK
F3 DI-08, 16 Setup S Parameter settings for a Digital Command Card OK OK OK OK
F4 AO-08, 12 Setup S Parameter settings for an Analog Monitor Card OK OK OK OK
F5 DO-02 Setup
Not Used. (Do not change these settings.) --- --- --- ---
F6 DO-08 Setup
o Used ( o ocage esese gs)
F7 PO-36F Setup S Parameter settings for a Pulse Monitor Card OK OK OK OK
F8 SI-F/G Setup S Parameter settings for a SYSMAC BUS Interface
Card.
OK OK OK OK
F9 CP-916 Setup S Parameter settings for a CompoBus/D Communica -
tions Card.
OK OK OK OK
Advanced Operation Chapter 6
