2-2-4 Wiring Around the Main Circuit
System
reliability
and noise resistance are af
fected by the wiring method used. There
-
fore,
always follow the instructions given below when connecting the Inverter to periph
-
eral devices and other parts.
H Wire Size and Round Solderless Terminal
For the main circuit and ground, always use 600-V polyvinyl chloride (PVC) cables.
If
the cable is long and may cause voltage drops, increase the wire size
according to the cable length.
