Omron SYSDRIVE 3G3FV User Manual

6-37
Group Control mode FunctionGroup
Flux
Vector
Open-loop
Vector
V/f
w/PG
V/f
Function
Options
F1 PG Option Setup Parameter settings for a PG Speed Control Card --- OK --- OK
Oos
F2 AI-14 Setup Parameter settings for an Analog Command Card OK OK OK OK
F3 DI-08, 16 Setup Parameter settings for a Digital Command Card OK OK OK OK
F4 AO-08, 12 Setup Parameter settings for an Analog Monitor Card OK OK OK OK
F5 Not used
(Do not change these settings.) --- --- --- ---
F6 Not used
(o ocage esese gs)
F7 PO-36F Setup Parameter settings for a Pulse Monitor Card OK OK OK OK
F8 SI-F/G Setup Parameter settings for a SYSMAC BUS Interface
Card.
OK OK OK OK
F9 CP-916 Setup Parameter settings for a CompoBus/D Communica -
tions Card.
OK OK OK OK
Terminal
H1 Digital Inputs Function selection for multi-function inputs OK OK OK OK
ea
H2 Digital Outputs Function selection for multi-function outputs OK OK OK OK
H3 Analog Inputs Adjustment/function selection for external analog
inputs
OK OK OK OK
H4 Analog Outputs Adjustment/function selection for multi-function ana -
log outputs
OK OK OK OK
H5 Not used (Do not change these settings.) --- --- --- ---
Protection
L1 Motor Overload Sets electrical/thermal functions that protect the mo -
tor.
OK OK OK OK
L2 PwrLoss Ridethru Selects the power-loss processing method. OK OK OK OK
L3 Stall Prevention Accel/Decel stall prevention settings and selection OK OK OK OK
L4 Ref Detection Frequency detection settings and selection OK OK OK OK
L5 Fault Restart Fault restart function settings OK OK OK OK
L6 T orque Detection Sets overtorque detection functions 1 and 2 OK OK OK OK
L7 T orque Limit Not used. (Can’t be set.) --- --- OK OK
L8 Hdwe Protection Hardware overheating and phase loss protection
settings
OK OK OK OK
Operator
o1 Monitor Select Selects the Operator ’ s display and setting methods. OK OK OK OK
Oeao
o2 Key Selections Operator’ s key function selection and other parame -
ters
OK OK OK OK
6-4-2 Energy-saving Control Function
The energy-saving control function is enabled when the energy-saving command (setting 63) has been
set in a multi-function input (H1-01 through H1-06). Inputting the energy-saving command while there is
a light load causes the Inverter ’ s output voltage to be reduced and saves energy . T urn OFF the energy-
saving command when a normal load is added.
Parameter
b8-01 determines the Inverter ’ s output voltage when the energy-saving command is input.
Set this value as a percentage of the V/f pattern’ s voltage. Parameter L2-04 (the voltage recovery time)
determines the rate at which the output voltage is changed when the energy-saving command is turned
ON or OFF.
Parameter b8-02 determines the lower limit frequency for the energy-saving function. The energy-sav -
ing command is enabled only when the frequency reference is above this lower limit and the motor
speed is within the “speed agree” range.
Advanced Operation Chapter 6
