5-10
H Presetting Frequency Reference Values (d1-01 through d1-09)
Parameters
d1-01 through d1-08 contain preset reference values 1 through 8. The setting range for all
of the values is 0 to the max. frequency. These 8 parameters can be changed during operation.
Parameter Display name Setting Units Default
Valid access levels
number
range setting
V/f
Control
V/f with
PG
Open Loop
Vector
Flux
Vector
d1-01 Reference 1 0 to max. o1-03 6.00 Hz Quick-start, Basic, or Advanced
d1-02 Reference 2 0 to max. o1-03 0.00 Hz Quick-start, Basic, or Advanced
d1-03 Reference 3 0 to max. o1-03 0.00 Hz Quick-start, Basic, or Advanced
d1-04 Reference 4 0 to max. o1-03 0.00 Hz Quick-start, Basic, or Advanced
d1-05 Reference 5 0 to max. o1-03 0.00 Hz Basic or Advanced
d1-06 Reference 6 0 to max. o1-03 0.00 Hz Basic or Advanced
d1-07 Reference 7 0 to max. o1-03 0.00 Hz Basic or Advanced
d1-08 Reference 8 0 to max. o1-03 0.00 Hz Basic or Advanced
Note 1. The units for these values are set in o1-03.
Note 2. The frequency reference’s initial value and set value will change when o1-03 is changed.
For
example, if preset reference 1 is set to 6.00 Hz and o1-03 is
changed to 1 (0.01% units),
the setting for preset reference 1 will become 10.00%.
Note 3. When
using preset references 2 through 8, be sure to set Multi-Step Reference 1, 2, and 3 in
the multi-function inputs (H1-01 through H1-06) as required.
When
using the Jog function, set the jog frequency reference in parameter d1-09. The
setting range for
this value is 0 to the max. frequency. This parameter can be changed during operation.
Parameter Display name Setting Units Default
Valid access levels
number
range setting
V/f
Control
V/f with
PG
Open Loop
Vector
Flux
Vector
d1-09 Jog Reference 0 to max. o1-03 6.00 Hz Quick-start, Basic, or Advanced
Note 1. When performing the Jog operation from an external terminal, set the multi-function inputs
(H1-01 through H1-06) to “Jog Frequency Reference,” “Forward Jog,” or “Reverse Jog” as
required.
Note 2. The
multi-function input setting is unnecessary when performing the Jog operation from the
Operator.
5-1-4 Run Source and Responsiveness Settings
H Selecting the Run Source (b1-02)
Parameter
b1-02 is used to select the
source of the run command; it cannot be changed during opera
-
tion.
When a
control circuit terminal (external terminal) is set, the Unit operates with 2-wire forward/stop
and
reverse/stop control. (When the Unit has been initialized for a 3-wire control or a multi-function
input
is set to “0” (3-wire control), the Unit operates with 3-wire run, stop and forward/reverse control.)
Parameter Display name Setting Units Default
Valid access levels
number
