6-41
Group Control mode CommentsFunctionGroup
Flux
Vector
Open-loop
Vector
V/f
w/PG
V/f
CommentsFunction
Terminal
H1 Digital Inputs S Function selection for multi-function inputs OK OK OK OK
ea
H2 Digital Outputs S Function selection for multi-function outputs OK OK OK OK
H3 Analog Inputs S Adjustment/function selection for external analog in -
puts
OK OK OK OK
H4 Analog Outputs S Adjustment/function selection for multi-function analog
outputs
OK OK OK OK
H5 Serial Com Setup Not Used. (Do not change this setting.) --- --- --- ---
Protection
L1 Motor Overload S Sets electrical/thermal functions that protect the motor . OK OK OK OK
oec o
L2 PwrLoss Ridethru S Selects the power-loss processing method. OK OK OK OK
L3 Stall Prevention S Accel/Decel stall prevention settings and selection OK OK OK OK
L4 Ref Detection S Frequency detection settings and selection OK OK OK OK
L5 Fault Restart S Fault restart function settings OK OK OK OK
L6 T orque Detection S Sets overtorque detection functions 1 and 2 OK OK OK OK
L7 T orque Limit T orque limit settings --- --- OK OK
L8 Hdwe Protection S Hardware overheating and phase loss protection set -
tings
OK OK OK OK
Operator
o1 Monitor Select S Selects the Operator ’ s display and setting methods. OK OK OK OK
Oeao
o2 Key Selections S Operator ’ s key function selection and other parame -
ters
OK OK OK OK
6-5-2 Application Parameters (b)
H Setting Operation Source Selection (b1)
• The input methods of parameters or frequency references and the operation methods of the run com -
mand
can be set in the Inverter in operation mode. In addition, the following advanced functions are
available.
• The
run command already set in the Inverter can be disabled or enabled when switching the Inverter to
local mode from remote mode.
• The
run command already set in the Inverter in any mode other than drive mode can be disabled or
enabled.
• Set the parameter according to the application.
Parameter Display name Setting Units Default
Valid access levels
number
py
g
range setting
V/f
Control
V/f with
PG
Open Loop
Vector
Flux
Vector
b1-07 LOC/REM RUN
Set
0, 1 --- 0 Advanced
Explanation of Settings
Setting Description
0 The run command already set is disabled (when the Inverter is switched to local mode
from remote mode. The Inverter will start operating with the run command input again.)
1 The run command already set is enabled (and the Inverter will start operating according
to the present run command when the Inverter is switched to local mode from remote
mode).
Note If parameter b1-07 (LOC/REM RUN Sel) is set to 1, the run command will not be ignored. In this
case, an Inverter may start operating immediately when switched to remote mode from local
mode. Take necessary measures for safety.
Advanced Operation Chapter 6
