5-11
Run Source Settings
Setting Name Run source
0 Operator Digital Operator
1 Terminals Control circuit terminals (external terminals)
2 Serial Com Not used. (Do not set.)
3 Option PCB Optional Card (CompoBus/D Communications Card or SYSMAC BUS I/F
Card)
4 EWS Not used. (Do not set.)
H Setting Control Input Responsiveness (b1-06)
Parameter b1-06 is used to set the responsiveness of the control inputs (forward/reverse and multi-
function inputs); it cannot be changed during operation.
Parameter Display name Setting Units Default
Valid access levels
number
range setting
V/f
Control
V/f with
PG
Open Loop
Vector
Flux
Vector
b1-06 Cntl Input Scans 0 or 1 --- 1 Advanced
Settings
Setting Name Function
0 2mS – 2 Scans Two scans every 2 ms (Use when connecting transistor outputs.)
1 5mS – 2 Scans Two scans every 5 ms (Use when connecting contact outputs or switches.)
Note Set
the responsiveness to match the type of control inputs being used. Use a setting of “1” if there
is even one contact input.
5-1-5 Acceleration/Deceleration
T
ime Settings
H Acceleration/Deceleration Time Units (C1-10)
Parameter
C1-10 is used to set the units for the acceleration and deceleration time settings in C1-01
through
C1-08. Setting C1-10 to “0” allows the acceleration and
deceleration times to be set very pre
-
cisely, but reduces the maximum time setting from 6000.0 s to 600.00 s.
This parameter cannot be changed during operation.
Parameter Display name Setting Units Default
Valid access levels
number
range setting
V/f
Control
V/f with
PG
Open Loop
Vector
Flux
Vector
C1-10 Acc/Dec Units 0 or 1 --- 1 Advanced
Settings
Setting Name Function
0 0.01 Seconds Sets the acceleration/deceleration time units to 0.01 seconds.
1 0.1 Seconds Sets the acceleration/deceleration time units to 0.1 seconds.
H Acceleration/Deceleration Time Settings (C1-01 through C1-08)
Parameters C1-01 through C1-08 set the acceleration and deceleration times individually.
Basic Operation Chapter
5
To Next Page
