6-77
6-5-7 External Terminal Functions: H
H Multi-function Input Settings (H1)
Setting Function
Control mode
g
V/f V/f
w/PG
Open-loop
Vector
Flux
Vector
0 3-Wire Control (with a forward/reverse rotation input) OK OK OK OK
1 Local/Remote Selection (operation signal selection) OK OK OK OK
2 Option/Inverter Selection (ON: Optional Card) OK OK OK OK
3 Multi-Step Reference 1
Switches between main speed and auxiliary speed when
parameter H3-05 is set to 0 (auxiliary frequency reference).
OK OK OK OK
4 Multi-Step Reference 2 OK OK OK OK
5 Multi-Step Reference 3 OK OK OK OK
6 Jog Frequency Reference (higher priority than multi-step) OK OK OK OK
7 Multi-Accel/Decel 1 (accel/decel time selector 1) OK OK OK OK
8 External Baseblock N.O. (normally open contact) OK OK OK OK
9 External Baseblock N.C. (normally closed contact) OK OK OK OK
A Accel/Decel Ramp Hold (Pauses acceleration/deceleration.) OK OK OK OK
B OH2 Alarm Signal (Inverter overheating warning) OK OK OK OK
C Terminal 16 Enable (Enables the multi-function analog input.) OK OK OK OK
D ASR Selection
(Disables PG feedback and switches to normal V/f control.)
--- OK --- ---
E ASR Integral Reset (Disables integral control.) --- OK --- OK
F Not used. (Do not input this setting.) --- --- --- ---
10 UP command (Always used with the DOWN command.) OK OK OK OK
11 DOWN command (Always used with the UP command.) OK OK OK OK
12 Forward Jog command (Forward jog at the speed in d1-09.) OK OK OK OK
13 Reverse Jog command (Reverse jog at the speed in d1-09.) OK OK OK OK
14 Fault Reset (Faults are reset when input goes OFF → ON.) OK OK OK OK
15 Fast-Stop
(Emergency stop using the deceleration time in C1-09.)
OK OK OK OK
16 Motor 2 Selection
Selection of motor 1 or motor 2 for two-motor switching
(ON: Motor 2 selected)
OK OK OK OK
17 Fast-stop N.C. (OFF: Decelerates to a stop when the
emergency stop time set with C1-09 elapses.)
OK OK OK OK
18 Timer Function Input
(Used with the b4 ON/OFF delay timers and timer output.)
OK OK OK OK
19 PID Disable (Disables PID control.) OK OK OK OK
1A Multi-Accel/Decel 2 (accel/decel time selector 2) OK OK OK OK
1B Program Lockout (Parameters write-protected when OFF.) OK OK OK OK
1C Trim Control Increase (Adds the d4-02 trim control level to
the analog frequency reference.)
OK OK OK OK
1D Trim Control Decrease (Subtracts the d4-02 trim control level
from the analog frequency reference.)
OK OK OK OK
1E Ref Sample Hold (ON: Retains the analog value.) OK OK OK OK
Advanced Operation Chapter 6
