Omron SYSDRIVE 3G3FV User Manual

3-27
C2 S-curve
characteristic setting
Operation mode
Initialize mode
Program mode
b Application
c Tuning
[Mode] [Group] [Function] [Parameter]
Auto-tuning
mode
Modified constants
mode
b1 Sequence b1-01 Reference Source
b1-02 Run Source
b1-03 Stopping Method
C1-01 Acceleration time 1
C1-02 Deceleration time 1
C1 Accel/Decel
b2 DC braking
b3 Speed search
b2-01 Zero speed Level
b2-02 DC Inj Current
b3-01 Spd Srch at Start
b3-02 Spd Srch Current
MENU
ADVANCED
BASIC
QUICK-START
C2-01 SCrv Acc @ Start
C2-02 SCrv Acc @ End
C3-01 Slip Comp Gain
C3 Motor-slip
compensation
d Reference
d2 Frequency
upper/lower limit
d1-01 Preset reference 1
d1-02 Preset reference 2
d1 Frequency
reference presetting
d2-01 Ref Upper Limit
d2-02 Ref Lower Limit
d3-01 Jump Freq 1
d3 Jump frequency
E Motor
E2 Motor setup
E1-01 Input V oltage
E1-02 Motor Selection
E1 V/F pattern
setting
E2-01 Motor Rated FLA
F Options
F1-01 PG Pulses/Rev
F1 PG Speed
Control Card
H Terminal
H1-01 T erminal 3 Sel
H2-01 T erminal 9 Sel
H1 Multi-function
input
H2 Multi-function
output
L Protection
L1-01 MOL Fault Select
L1-02 MOL T ime Const
L1 Motor protection
L2 instantaneous power
failure compensation
o2 Function
selection
o Operator
o1-01 User Monitor Sel
o1-02 Power-On Monitor
o1 Display/setting
selection
o2-01 Local/Remote Key
o2-02 Oper Stop Key
Note The above parameter levels are simplified levels used mainly in programming operation.
Preparing for Operation Chapter 3
