5-36
Note The voltage settings shown in parentheses are the values for the 400-V class.
H Motor Selection Setting (E1-02)
Set
the motor selection (E1-02) to the type of motor to be used. This setting is used as a basis for motor
protection
Parameter Display Setting Units Default
Valid access levels
number
range setting
V/f
Control
V/f with
PG
Open Loop
Vector
Flux
Vector
E1-02 Motor Selec-
tion
0 to 2 --- 0 Quick-start
D Setting
Setting Function
0 Standard fan-cooled motor (general-purpose motor)
1 Standard blower motor (inverter-exclusive motor)
2 Special motor (special vector control motor)
H Precautions Before Auto-tuning
Caution Do
not connect a load to the motor when performing auto-tuning. Doing so may re
-
sult in personal injury or equipment damage.
• The
Inverter
’
s auto-tuning function automatically determines the motor parameters while a servo sys
-
tem’s auto-tuning function determines the size of a load, so these auto-tuning functions are funda-
mentally different.
• If
a load is connected when auto-tuning is performed, not only will incorrect motor parameters be re
-
corded, but the motor may operate erratically resulting in dangerous conditions such as loads
falling
from vertical axis motors. Never perform auto-tuning with a load connected to the motor.
H Required Parameter Settings
Enter auto-tuning mode and make the following parameter settings:
Rated Voltage: Set the rated voltage (VAC) shown on the motor’s nameplate.
Rated Current: Set the rated current (A) shown on the motor’s nameplate.
Rated Frequency: Set the rated frequency (Hz) shown on the motor’s nameplate.
Rated Speed: Set the rated speed (r/min) shown on the motor’s nameplate.
Number of poles: Set the number of poles.
Motor Selection: Select motor 1.
For two-motor switching control, select motor 1 or motor 2.
PG Pulses/Rev: Set the number of A-phase or B-phase pulses per revolution.
The following message will appear when the parameters have been set:
Tuning Ready ?
Press RUN key
At
this point, it is still possible to change the parameter settings by pressing the Increment and Decre
-
ment Keys to display the desired parameter.
Basic Operation Chapter
5
