H SYSDRIVE 3G3FV Inverter Models
• The following 200- and 400-V class 3G3FV Inverter models are available.
• A
total of 21 types of Inverters are available for maximum applicable motor capacities of 0.4 to 300 kW .
Voltage class Protective structure Maximum applied motor capacity Model
200-V class
(h)
NEMA1 type
0.4 kW 3G3FV-A2004
(3-phase)
y
0.75 kW 3G3FV-A2007
1.5 kW 3G3FV-A2015
2.2 kW 3G3FV-A2022
3.7 kW 3G3FV-A2037
5.5 kW 3G3FV-A2055
7.5 kW 3G3FV-A2075
11 kW 3G3FV-A2110
15 kW 3G3FV-A2150
Open chassis type
18.5 kW 3G3FV-B2185
y
22 kW 3G3FV-B2220
30 kW 3G3FV-B2300
37 kW 3G3FV-B2370
45 kW 3G3FV-B2450
55 kW 3G3FV-B2550
75 kW 3G3FV-B2750-E
400-V class
(h)
NEMA1 type
0.4 kW 3G3FV-A4004
(3-phase)
y
0.75 kW 3G3FV-A4007
1.5 kW 3G3FV-A4015
2.2 kW 3G3FV-A4022
3.7 kW 3G3FV-A4037
5.5 kW 3G3FV-A4055
7.5 kW 3G3FV-A4075
11 kW 3G3FV-A4110
15 kW 3G3FV-A4150
Open chassis type
18.5 kW 3G3FV-B4185
y
22 kW 3G3FV-B4220
30 kW 3G3FV-B4300
37 kW 3G3FV-B4370
45 kW 3G3FV-B4450
55 kW 3G3FV-B4550
75 kW 3G3FV-B4750-E
110 kW 3G3FV-B411K-E
160 kW 3G3FV-B416K-E
185 kW 3G3FV-B418K-E
220 kW 3G3FV-B422K-E
300 kW 3G3FV-B430K-E
