Page #346 background image
8-4
Fault Display Probable causes and remediesMeaning
LF
Output Pha Loss
A phase loss occurred at the
Inverter’s output.
This fault is detected when
L8-07 is set to “Enabled.”
There is a broken wire in the output cable.
There is a broken wire in the motor’s winding.
The output terminals are loose.
Reset the fault after correcting its cause.
The
motor being used has a capacity less than
10%
of the Inverter’s maximum motor capacity.
Check the motor and Inverter capacity.
OH
Heatsink Over tmp
The temperature of the
Inverter’s cooling fins
exceeded the setting in L8-02
or 105C.
The ambient temperature is too high.
Install a cooling unit.
There is a heat source nearby.
Remove the heat source.
The Inverter’s cooling fan has stopped.
Replace the cooling fan.
(Contact your OMRON representative.)
High carrier frequency. (400V-class models)
Decrease the C6-01 setting.
RH
Dyn Brk Resistor
The braking resistor is
overheated and the protection
function set with L8-01 has
operated.
The deceleration time is too short and the regen-
erative energy from the motor is too large.
Lighten the load, increase the deceleration
time, or reduce the motor speed.
Change to a Braking Resistor Unit.
RR
Dyn Brk Transistr
The braking transistor is not
operating properly.
Try turning the power supply off and on.
Replace
the
Inverter if the fault continues to oc
-
cur.
OL1
Motor Overloaded
The motor overload protection
function has operated based
on the internal electronic
thermal value.
The
load is too large. The acceleration time, decel
-
eration time, and cycle time are too short.
Check
the size of the load and the
length of the
acceleration, deceleration, and cycle times.
The V/f characteristics voltage is too high.
Check the V/f characteristics.
The motor’s rated current setting (E2-01) is incor-
rect.
Check the motors rated current setting
(E2-01).
OL2
Inv Overloaded
The Inverter overload
protection function has
operated based on the internal
electronic thermal value.
The
load is too large. The acceleration time, decel
-
eration time and cycle time are too short.
Check
the size of the load and the
length of the
acceleration, deceleration, and cycle times.
The V/f characteristics voltage is too high.
Check the V/f characteristics.
The Inverter’s capacity is too low.
Replace
the Inverter with one that has a larger
capacity.
High carrier frequency.
Decrease the C6-01 setting.
Maintenance Operations Chapter
8
