Omron SYSDRIVE 3G3MV SERIES User Manual

10-4
Param-
eter
No.
Ref-
er-
ence
page
Changes
during
opera-
tion
Default
setting
Unit
of
set-
ting
Set-
ting
range
DescriptionNameRegis-
ter No.
(Hex)
n004 0104 Frequency
reference
selection
Used to set the input method for the
frequency reference in remote mode.
0: Digital Operator
1: Frequency reference 1 (n024)
2: Frequency reference control termi-
nal (0 to 10 V)
3: Frequency reference control termi-
nal (4 to 20 mA)
4: Frequency reference control termi-
nal (0 to 20 mA)
5: Pulse train reference control termi-
nal is enabled.
6: Frequency reference through
RS-422/RS-485 is enabled.
7: Multi-function analog voltage input
(0 to 10 V) is enabled.
8: Multi-function analog current input
(4 to 20 mA) is enabled.
9: Frequency reference input through
DeviceNet communications is
enabled.
0 to 9 1 0 No 5-11
n005 0105 Stopping
method
selection
Used to set the stopping method for
use when the STOP command is
input.
0: Decelerates to stop in preset time.
1: Coasts to stop (with output turned
OFF by the STOP command)
0, 1 1 0 No 5-29
n006 0106 Reverse rota-
tion-prohibit
selection
Used to select the operation with the
reverse command input.
0: Reverse enabled (accept).
1: Reverse disabled (not accept).
0, 1 1 0 No 5-28
n007 0107 STOP Key
function
selection
Used to enable/disable the STOP Key
in remote mode with n003 for opera-
tion mode selection not set to 0.
0: STOP Key of the Digital Operator
enabled.
1: STOP Key of the Digital Operator
disabled.
0, 1 1 0 No 5-10
n008 0108 Frequency
reference
selection in
local mode
Used to set the input method for the
frequency reference in local mode.
0: The FREQ adjuster of the Digital
Operator enabled.
1: Key sequences on the Digital
Operator enabled. (Set in n024.)
0, 1 1 0 No 5-12
n009 0109 Operator fre-
quency set-
ting method
selection
Used to enable the Enter Key for set-
ting the frequency reference with the
Increment and Decrement Keys.
0: The value is entered with the Enter
Key pressed.
1: The value is enabled when the
value is input.
0, 1 1 0 No 5-22
List of Parameters Chapter 10

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
