10-5
Param-
eter
No.
Ref-
er-
ence
page
Changes
during
opera-
tion
Default
setting
Unit
of
set-
ting
Set-
ting
range
DescriptionNameRegis-
ter No.
(Hex)
n010 010A Operation
selection at
Digital Opera-
tor interrup-
tion
Select whether or not to detect the
OPR error (Digital Operator connec-
tion error).
0: No (The Inverter continues operat-
ing.)
1: Yes
(Error output turns ON and the
Inverter coasts to a stop)
0, 1 1 0 No 6-39
n011 010B Maximum fre-
quency
(FMAX)
Used to set the V/f pattern as the
basic characteristic of the Inverter.
V/f control mode: set output voltage
per frequency
Vector control mode: set for torque
adjustment
50.0 to
400.0
0.1
Hz
60.0 No 5-7
n012 010C Maximum
voltage
(VMAX)
Output
voltage
n012
(V)
0.1 to
255.0
(0.1 to
510.0)
0.1 V 200.0
(400.0)
(See
note 1.)
No 5-7
n013 010D Maximum
voltage fre-
quency (FA)
Fre-
n015
n017
0.2 to
400.0
0.1
Hz
60.0 No 5-7
n014 010E Middle output
frequency
(FB)
Fre
quency
(Hz)
* Set the parameters so that the
following condition will be satisfied
n016 n014 n013 n011
0.1 to
399.9
0.1
Hz
1.5 No 5-7
n015 010F Middle output
frequency
voltage (VC)
f
o
ll
ow
i
ng con
diti
on w
ill b
e sa
ti
s
fi
e
d
.
n016 x n014 < n013 x n011
* The value set in n015 will be
ignored if parameters n016 and
n014 have the same value
0.1 to
255.0
(0.1 to
510.0)
0.1 V 12.0
(24.0)
(See
note 2.)
No 5-7
n016 0110 Minimum out-
put frequency
(FMIN)
n014 have the same value.
0.1 to
10.0
0.1
Hz
1.5 No 5-7
n017 0111 Minimum out-
put frequency
voltage
(VMIN)
0.1 to
50.0
(0.1 to
100.0)
0.1 V 12.0
(24.0)
(See
note 2)
No 5-7
n018 0112 Acceleration/
Deceleration
time setting
Unit (n018)
Select the unit of acceleration or
deceleration time of the Inverter.
0: 0.1 s Unit
(Less than 1,000 s: 0.1-s incre-
ments; 1,000 s or over: 1-s incre-
ments)
1: 0.01 s Unit
(Less than 100 s: 0.01-s incre-
ments; 100 s or over: 0.1-s incre-
ments)
0, 1 1 0 No 5-25
Note 1. The values in brackets are those for 400-V-class Inverters.
Note 2. For 200 and 400-V-class 5.5-/7.7-kW Inverters, this value is 10.0 V (20.0 V).
List of Parameters Chapter 10
