Omron SYSDRIVE 3G3MV SERIES User Manual

10-6
Param-
eter
No.
Regis-
ter No.
(Hex)
Name Description Set-
ting
range
Unit
of
set-
ting
Default
setting
Changes
during
opera-
tion
Ref-
er-
ence
page
n019 0113 Acceleration
time 1
Acceleration time: The time required
to go from 0% to 100% of the maxi-
mum frequency.
0.0 to
6,000
0.1 s
(chan
ge in
n018)
10.0 Yes 5-25
n020 0114 Deceleration
time 1
Deceleration time: The time required
to go from 100% to 0% of the maxi-
mum frequency.
n018)
10.0 Yes 5-25
n021 0115 Acceleration
time 2
* The actual acceleration or decel-
eration time is obtained from the
following formula.
Acceleration/Deceleration time =
10.0 Yes 5-25
n022 0116 Deceleration
time 2
A
cce
l
era
ti
on
/D
ece
l
era
ti
on
ti
me =
(Acceleration/Deceleration time set
value) × (Frequency reference
value) ÷ (Max. frequency)
10.0 Yes 5-25
n023 0117 S-shape
acceleration/
deceleration
characteristic
Used to set S-shape acceleration/de-
celeration characteristics.
0: No S-shape acceleration/decelera-
tion (trapezoidal acceleration/de-
celeration)
1: S-shape acceleration/deceleration
characteristic time 0.2 s
2: S-shape acceleration/deceleration
characteristic time 0.5 s
3: S-shape acceleration/deceleration
characteristic time 1.0 s
* When the S-shape acceleration/
deceleration characteristic time is
set, the acceleration and decelera-
tion times will be lengthened
according to the S-shape at the
beginning and end of acceleration/
deceleration.
0 to 3 1 0 No 5-27
n024 0118 Frequency
reference 1
Used to set internal frequency refer-
ences.
0.0 to
max.
fre
0.01
Hz
(
6.00 Yes 5-19
n025 0119 Frequency
reference 2
e ces
* Frequency reference 1 is enabled
in remote mode with n004 for fre-
fre-
quency
(chan
ge in
n035)
0.00 Yes 5-19
n026 011A Frequency
reference 3
in remote mode with n004 for fre
quency reference selection set to
1.
n035)
0.00 Yes 5-19
n027 011B Frequency
reference 4
* These frequency references are
selected with multi-step speed ref-
(lif ii )S
0.00 Yes 5-19
n028 011C Frequency
reference 5
pp
erences (multi-function input). See
the reference pages for the rela-
tionship between multi step speed
0.00 Yes 5-19
n029 011D Frequency
reference 6
t
i
ons
hi
p
b
etween mu
l
t
i
-step spee
d
references and frequency refer-
ences.
0.00 Yes 5-19
n030 011E Frequency
reference 7
ences
.
0.00 Yes 5-19
n031 011F Frequency
reference 8
0.00 Yes 5-19
n032 0120 Inching fre-
quency com-
mand
Used to set the inching frequency
command.
* The inching frequency command is
selected with the inching command
(multi-function input). The inching
frequency command takes prece-
dence over the multi-step speed
reference.
6.00 Yes 5-21
List of Parameters Chapter 10

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
