Omron SYSDRIVE 3G3MV SERIES User Manual

10-11
Para
me-
ter
No.
Reg-
ister
No.
(Hex)
Name Description Set-
ting
range
Unit
of
set-
ting
Default
setting
Chan-
ges dur-
ing
opera-
tion
Ref-
er-
ence
page
6 Multi-step
speed ref-
erence 1
Signals to select fre-
quency references 1
through 16.
7 Multi-step
speed ref-
erence 2
g
Refer to 5-6-4 Setting
Frequency References
through Key
8 Multi-step
speed ref-
erence 3
through Key
Sequences for the
relationship between
multi-step speed refer-
ences and frequency
9 Multi-step
speed ref-
erence 4
ences and
f
requency
references.
10 Inching fre-
quency
command
ON: Inching frequency
command (taking pre-
cedence over the mul-
ti-step speed refer-
ence)
11 Accelera-
tion/decel-
eration time
selection 1
See set value 27.
12 External
base block
command
(NO)
ON: Output turned
OFF
13 External
base block
command
(NC)
OFF: Output turned
OFF
14 Search
command
(Searching
starts from
maximum
frequency)
ON: Speed search
(Searching starts from
n011)
15 Search
command
(Searching
starts from
preset fre-
quency)
ON: Speed search
16 Accelera-
tion/Decel-
eration-pro-
hibit com-
mand
ON: Acceleration/De-
celeration is on hold
(running at parameter
frequency)
17 Local or
remote
selection
ON: Local mode
(operated with the Dig-
ital Operator)
18 Commu-
nications/
remote
selection
ON: Communications
input is enabled.
List of Parameters Chapter 10

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
