Omron SYSDRIVE 3G3MV SERIES - Page 322

10-20
Para
me-
ter
No.
Ref-
er-
ence
page
Chan-
ges dur-
ing
opera-
tion
Defaul
t set-
ting
Unit
of
set-
ting
Set-
ting
range
DescriptionNameReg-
ister
No.
(Hex)
n074 014A Pulse train
frequency
reference
gain
Sets the input characteristics of pulse train
input.
Gain:Sets the gain in percentage based on the
maximum frequency of the pulse train
input scale in n149 as 100%
0 to
255
1% 100 Yes 5-23
n075 014B Pulse train
frequency
reference
bias
i
nput sca
l
e
i
n n149 as 100%.
Bias: Sets the bias in percentage for frequency
reference input at 0-Hz pulse train input
based on the maximum frequency as
100%.
–100
to 100
1% 0 Yes 5-23
n076 014C Pulse train
frequency
reference
input filter
constant
Sets the pulse train input’s primary-delay digital
filter for frequency reference.
0.00
to
2.00
0.01 s 0.10 Yes 5-24
n077 014D Multi-func-
tion analog
input termi-
nal func-
tion selec-
tion
Selects the function allocated to the multi-func-
tion analog input terminal.
0: Disable multi-function analog input function.
1: Auxiliary frequency reference
2: Frequency gain
3: Frequency bias
4: Output voltage bias
* When setting “3,” also set the standard val-
ue for the bias in n079.
0 to 4 1 0 No 5-14
n078 014E Multi-func-
tion analog
input termi-
nal selec-
tion
Selects whether voltage input or current input
is to be used.
0: Enable multi-function analog voltage input
(and disable current input).
1: Enable multi-function analog current input
(and disable voltage input).
0, 1 1 0 No 5-14
n079 014F Multi-func-
tion input
frequency
bias
When “3” is set for n077, set the standard val-
ue for the bias as a percentage, taking the
maximum frequency as 100%.
0 to
50
1 % 10 No 5-14
List of Parameters Chapter 10
