Omron V1000 User Manual

Drive
VZA
Filter Data (Manufacturer: Schaffner)
Type
Rated
Current
(A)
Weight
(kg)
Dimensions
[W x L x H] (mm)
Y x X
Drive
Mounting
Screw A
Filter
Mounting
Screw
400 V Three-Phase Units
40P2 A1000–FIV3005–SE 5 0.5 111 x 169 x 45 91 x 156 M4 M5
40P4 A1000–FIV3005–SE 5 0.5 111 x 169 x 45 91 x 156 M4 M5
40P7 A1000–FIV3005–SE 5 0.5 111 x 169 x 45 91 x 156 M4 M5
41P5 A1000–FIV3010–SE 10 0.7 111 x 169 x 45 91 x 156 M4 M5
42P2 A1000–FIV3010–SE 10 0.7 111 x 169 x 45 91 x 156 M4 M5
43P0 A1000–FIV3010–SE 10 0.7 111 x 169 x 45 91 x 156 M4 M5
44P0 A1000–FIV3020–SE 15 0.9 144 x 174 x 50 120 x 161 M4 M5
45P5 A1000–FIV3030–SE 30 1.8 137 x 304 x 56 100 x 289 M5 M5
47P5 A1000–FIV3030–SE 30 1.8 137 x 304 x 56 100 x 289 M5 M5
4011 A1000–FIV3050–SE 50 2.7 175 x 340 x 65 130 x 325 M5 M6
4015 A1000–FIV3050–SE 50 2.7 175 x 340 x 65 130 x 325 M5 M6
Note: Use filters manufactured by Rasmi as listed below only if the Safe Disable function of the drive is not part of the safety concept of a
machine or installation and not used for a safe stop according to EN60204-1, stop category 0. If the Safe Disable function of the drive is
part of the safety concept of a machine or installation, use filters manufactured by Schaffner as listed above.
Table D.3 EN 61800-3 Category C1 Filters
Drive VZA
Filter Data (Manufacturer: Rasmi)
Type
Rated
Current
(A)
Weight
(kg)
Dimensions
[W x L x H]
Y x X
Drive
Mounting
Screw A
Filter
Mounting
Screw
200 V Single-Phase Units
B0P1 A1000–FIV1010–RE 10 0.6 71 x 169 x 45 51 x 156 M4 M5
B0P2 A1000–FIV1010–RE 10 0.6 71 x 169 x 45 51 x 156 M4 M5
B0P4 A1000–FIV1010–RE 10 0.6 71 x 169 x 45 51 x 156 M4 M5
B0P7 A1000–FIV1020–RE 20 1.0 111 x 169 x 50 91 x 156 M4 M5
B1P5 A1000–FIV1020–RE 20 1.0 111 x 169 x 50 91 x 156 M4 M5
B2P2 A1000–FIV1030–RE 30 1.1 144 x 174 x 50 120 x 161 M4 M5
B4P0 A1000–FIV1040–RE 40 1.2 174 x 174 x 50 150 x 161 M4 M5
200 V Three-Phase Units
20P1 A1000–FIV2010–RE 10 0.8 82 x 194 x 50 62 x 181 M4 M5
20P2 A1000–FIV2010–RE 10 0.8 82 x 194 x 50 62 x 181 M4 M5
20P4 A1000–FIV2010–RE 10 0.8 82 x 194 x 50 62 x 181 M4 M5
20P7 A1000–FIV2010–RE 10 0.8 82 x 194 x 50 62 x 181 M4 M5
21P5 A1000–FIV2020–RE 16 1.0 111 x 169 x 50 91 x 156 M4 M5
22P2 A1000–FIV2020–RE 16 1.0 111 x 169 x 50 91 x 156 M4 M5
24P0 A1000–FIV2030–RE 26 1.3 144 x 174 x 50 120 x 161 M4 M5
25P5 A1000–FIV2060–RE 58 2.4 150 x 320 x 52 122 x 290 M5 M5
27P5 A1000–FIV2060–RE 58 2.4 150 x 320 x 52 122 x 290 M5 M5
2011 A1000–FIV2080–RE 78 4.2 188 x 362 x 62 160 x 330 M5 M6
2015 A1000–FIV2100–RE 96 4.4 220 x 415 x 62 192 x 380 M6 M6
400 V Three-Phase Units
40P2 A1000–FIV3005–RE 5 1.0 111 x 169 x 45 91 x 156 M4 M5
40P4 A1000–FIV3005–RE 5 1.0 111 x 169 x 45 91 x 156 M4 M5
40P7 A1000–FIV3005–RE 5 1.0 111 x 169 x 45 91 x 156 M4 M5
41P5 A1000–FIV3010–RE 10 1.0 111 x 169 x 45 91 x 156 M4 M5
42P2 A1000–FIV3010–RE 10 1.0 111 x 169 x 45 91 x 156 M4 M5
43P0 A1000–FIV3010–RE 10 1.0 111 x 169 x 45 91 x 156 M4 M5
44P0 A1000–FIV3020–RE 15 1.1 144 x 174 x 50 120 x 161 M4 M5
45P5 A1000–FIV3030–RE 29 2.0 150 x 306 x 52 122 x 290 M5 M5
47P5 A1000–FIV3030–RE 29 2.0 150 x 306 x 52 122 x 290 M5 M5
4011 A1000–FIV3050–RE 48 2.8 175 x 357 x 62 160 x 330 M5 M6
4015 A1000–FIV3050–RE 48 2.8 175 x 357 x 62 160 x 330 M5 M6
D.2 European Standards
386
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
