PCIe Card Installation Order Guidelines
“Card Installation Bottom CMIOU Chassis (Servers With Multiple
PDomains)” on page 146
“Card Installation Bottom CMIOU Chassis (SPARC M7 With One
PDomain)” on page 147
“Card Installation Top CMIOU Chassis (SPARC M7-16)” on page 148
Card Installation Bottom CMIOU Chassis (Servers
With Multiple PDomains)
For SPARC M8-8 and SPARC M7-8 servers with two PDomains and SPARC M7-16 servers,
install PCIe cards in fully populated configurations in the order shown.
No. PDomain CMIOU PCIe Slot Card to Install
1.
PDomain_0 CMIOU_0 PCI3
Storage card
2.
PDomain_0 CMIOU_1 PCI3
Network card
3.
PDomain_0 CMIOU_2 PCI3
4.
PDomain_1 CMIOU_4 PCI3
Storage card
5.
PDomain_1 CMIOU_5 PCI3
Network card
6.
PDomain_1 CMIOU_6 PCI3
7.
PDomain_0 CMIOU_0 PCI1
8.
PDomain_0 CMIOU_1 PCI1
9.
PDomain_0 CMIOU_2 PCI1
10.
PDomain_1 CMIOU_4 PCI1
11.
PDomain_1 CMIOU_5 PCI1
12.
PDomain_1 CMIOU_6 PCI1
13.
PDomain_0 CMIOU_3 PCI3
14.
PDomain_1 CMIOU_7 PCI3
15.
PDomain_0 CMIOU_3 PCI1
16.
PDomain_1 CMIOU_7 PCI1
17.
PDomain_0 CMIOU_0 PCI2
18.
PDomain_0 CMIOU_1 PCI2
19.
PDomain_0 CMIOU_2 PCI2
20.
PDomain_0 CMIOU_3 PCI2
21.
PDomain_1 CMIOU_4 PCI2
22.
PDomain_1 CMIOU_5 PCI2
146 SPARC M8 and SPARC M7 Servers Service Manual • September 2017
