Servicing Internal Interconnect Assemblies
In SPARC M8-8 and SPARC M7-8 servers, five internal interconnect assemblies in the CMIOU
chassis connect the CMIOUs to each other.
For the location of the internal interconnect assemblies, see “CMIOU Chassis Front
Components” on page 20.
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. This discharge can cause server components to fail. Follow antistatic precautions to
prevent electrostatic damage. See “Prevent ESD Damage” on page 61.
These topics explain how to service internal interconnect assemblies.
Step Description Links
1. Understand interconnect slot labels and configuration. “Internal Interconnect Assembly
Configuration” on page 298
2. Replace an internal interconnect assembly. “Remove an Internal Interconnect
Assembly” on page 299
“Install an Internal Interconnect
Assembly” on page 302
Related Information
■
“Identifying Components” on page 15
■
“Detecting and Managing Faults” on page 35
■
“Preparing for Service” on page 57
■
“Controlling the Server and Domains” on page 67
■
“Understanding Server Configurations and Failover Behavior” on page 79
Servicing Internal Interconnect Assemblies 297
