PCIe Card Installation Order Guidelines
Card Installation Top CMIOU Chassis (SPARC M7-
16)
Install PCIe cards in fully populated configurations in the order shown.
No. PDomain CMIOU PCIe Slot Card to Install
1.
PDomain_2 CMIOU_8 PCI3
Storage card
2.
PDomain_2 CMIOU_9 PCI3
Network card
3.
PDomain_2 CMIOU_10 PCI3
4.
PDomain_3 CMIOU_12 PCI3
Storage card
5.
PDomain_3 CMIOU_13 PCI3
Network card
6.
PDomain_3 CMIOU_14 PCI3
7.
PDomain_2 CMIOU_8 PCI1
8.
PDomain_2 CMIOU_9 PCI1
9.
PDomain_2 CMIOU_10 PCI1
10.
PDomain_3 CMIOU_12 PCI1
11.
PDomain_3 CMIOU_13 PCI1
12.
PDomain_3 CMIOU_14 PCI1
13.
PDomain_2 CMIOU_11 PCI3
14.
PDomain_3 CMIOU_15 PCI3
15.
PDomain_2 CMIOU_11 PCI1
16.
PDomain_3 CMIOU_15 PCI1
17.
PDomain_2 CMIOU_8 PCI2
18.
PDomain_2 CMIOU_9 PCI2
19.
PDomain_2 CMIOU_10 PCI2
20.
PDomain_2 CMIOU_11 PCI2
21.
PDomain_3 CMIOU_12 PCI2
22.
PDomain_3 CMIOU_13 PCI2
23.
PDomain_3 CMIOU_14 PCI2
24.
PDomain_3 CMIOU_15 PCI2
Related Information
■
“PCIe Card Slot Configuration and Numbering” on page 142
■
“Understanding PCIe Card Device and Service Paths” on page 143
148 SPARC M8 and SPARC M7 Servers Service Manual • September 2017
