Install a Switch Chassis
Install a Switch Chassis
1.
If you have not already done so, remove the faulty switch chassis.
See “Remove a Switch Chassis” on page 277.
2.
Determine your next step:
■ If you have another person to assist you, go to Step 4.
■ If you are alone, go to Step 3.
3.
Place the chassis on a mechanical lift.
4.
Install the chassis into the rack, and secure the chassis with the five screws that
were removed.
5.
At the front of the server, install these components.
Component Link
SP interconnect “Servicing SP Internal Interconnect
Assemblies” on page 285
External interconnects “Servicing External Interconnect
Assemblies” on page 305
6.
At the rear of the server, install these components.
Component Link
Power module, which includes the AC input strip and
the front indicator panel
“Servicing Power Modules” on page 235
PDECBs “Servicing PDECBs” on page 199
Switch units “Servicing Switch Units” on page 189
SP tray “Servicing SP Trays” on page 243
SPs “Servicing SPs” on page 117
Cables Ensure that you install the cables in the same slots from
which you removed them.
7.
At the front of the server, install the power supplies.
See “Servicing Power Supplies” on page 165.
Servicing the Switch Chassis 283
