Install a CMIOU Chassis
Install a CMIOU Chassis
1.
If you have not already done so, remove the faulty CMIOU chassis.
See “Remove a CMIOU Chassis” on page 269.
2.
Determine your next step:
■ If you have another person to assist you, go to Step 4.
■ If you are alone, go to Step 3.
3.
Place the chassis on a mechanical lift.
4.
Install the chassis into the rack and secure the chassis with the five screws that
were removed.
5.
At the front of the server, install these components.
Component Link
Interconnects “Servicing Internal Interconnect Assemblies” on page 297
“Servicing External Interconnect Assemblies” on page 305
“Servicing SP Internal Interconnect Assemblies” on page 285
Fan modules “Servicing Fan Modules (CMIOU Chassis)” on page 179
6.
At the rear of the server, install these components.
Component Link
Power modules “Servicing Power Modules” on page 235
PDECBs “Servicing PDECBs” on page 199
Switch units (SPARC M7-16) “Servicing Switch Units” on page 189
CMIOUs “Servicing CMIOUs” on page 83
Fan modules (SPARC M7-16) “Servicing Fan Modules (Switch Chassis)” on page 183
SP tray “Servicing SP Trays” on page 243
SPs “Servicing SPs” on page 117
Cables Ensure that you install the cables in the same slots from
which you removed them.
7.
At the front of the server, install the power supplies.
Servicing the CMIOU Chassis 275
