Servicing SP Internal Interconnect Assemblies
There is one SP internal interconnect assembly in each CMIOU chassis. These assemblies
connect the CMIOUs to the SPs.
There is one SP internal interconnect assembly in the switch chassis. This assembly connects
switch units to the SPs.
For the location of the SP internal interconnect assemblies, see “CMIOU Chassis
Front Components” on page 20 and “Switch Chassis Front Components (SPARC
M7-16)” on page 23.
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. This discharge can cause server components to fail. Follow antistatic precautions to
prevent electrostatic damage. See “Prevent ESD Damage” on page 61.
These topics explain how to service SP internal interconnect assemblies.
Step Description Links
1. Understand SP internal interconnect naming. “CMIOU Chassis Rear Components” on page 21
“Switch Chassis Rear Components (SPARC
M7-16)” on page 25
2. Replace an SP internal interconnect assembly. “Remove an SP Internal Interconnect
Assembly” on page 286
“Install an SP Internal Interconnect
Assembly” on page 290
Related Information
■
“Identifying Components” on page 15
■
“Detecting and Managing Faults” on page 35
■
“Preparing for Service” on page 57
■
“Controlling the Server and Domains” on page 67
Servicing SP Internal Interconnect Assemblies 285
