Servicing the Front Indicator Panel
The front indicator panel is located on the front of the CMIOU chassis for SPARC M8-8 and
SPARC M7-8 servers, and on the front of the CMIOU chassis and switch chassis for SPARC
M7-16 servers. The service procedures are the same on either chassis. For the location of the
front indicator panel, see “CMIOU Chassis Front Components” on page 20 or “Switch Chassis
Front Components (SPARC M7-16)” on page 23.
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. This discharge can cause server components to fail. Follow antistatic precautions to
prevent electrostatic damage. See “Prevent ESD Damage” on page 61.
These topics explain how to service the front indicator panel.
■
“Remove a Front Indicator Panel” on page 217
■
“Install a Front Indicator Panel” on page 222
Related Information
■
“Front Indicator Panel Controls and LEDs” on page 46
■
“Identifying Components” on page 15
■
“Detecting and Managing Faults” on page 35
■
“Preparing for Service” on page 57
■
“Controlling the Server and Domains” on page 67
■
“Understanding Server Configurations and Failover Behavior” on page 79
Remove a Front Indicator Panel
This procedure can be performed only by qualified service personnel.
Caution - Remove AC power using the circuit breakers on the appropriate PDU before
performing this procedure.
Servicing the Front Indicator Panel 217
